400G AOC

Model 400G QSFP112 Active Optical Cable 10M

Sales: 99999 Stock: Available/Deliverable

Product Introduction:
Max. Power Consumption 10W Per End
Tested in Targeted Switches for Superior Performance, Quality, and Reliability
Increased Reliability-VCSEL, No MPO Connectors, Low BER
Thin and Light Weight Fiber with High Air Flow for Flexible Routing
OFNP-rated, Resistant to High Temperature and Corrosion
High-speed Electrical Compliant to IEEE 802.3ck
4x100G PAM4 Retimed 400GAUI-4 Electrical Interface
Hot Pluggable QSFP112 MSA Compliant
Digital Optical Monitoring Capability for Strong Diagnostic Capabilities
Inquiry
Product Details

The QSFP-400G-AO10 active optical cable is an 4-channel, pluggable, parallel, fiber optic 400G QSFP112 AOC. This active optical cable is compliant with QSFP112 MSA and IEEE 802.3 ck-400GAUI-4.
Thin and lightweight AOC cables simplify cable management, enabling an efficient system airflow, which is critical in high-density racks. It is used extensively in cloud and supercomputers due to its low cost, high-value proposition, and increased reliability.

Specifications
Part Number
QSFP-400G-AO10
Vendor Name
CY COM
Form Factor
QSFP112 to QSFP112
Max. Data Rate
400Gbps
Cable Length
10m (33ft)
Cable Type
AOC
Wavelength
850nm
Minimum Bend Radius
30mm
Transmitter Type
VSCEL
Receiver Type
PIN
Power Consumption
≤10W Per End
Jacket Material
OFNP
CDR (Clock and Data Recovery)
TX & RX Built-in CDR
Modulation Format
4x 100G-PAM4
DDM/DOM
Supported
Temperature Range
0 to 70°C (32 to 158°F)
Protocols
CMIS 4.0, IEEE 802.3 ck-400GAUI-4, QSFP112 MSA
Warranty
5 Years
